Description
-
Commercial model 55A6K Factory model 55A51HXVT Factory Qingdao Description 139cm (55″ ) Direct LED Television Document Specifications form version HA230216 Circulation Restricted, internal use only Status Confirmed Revision number 1 Date 2023/02/16 Issued by Al Image display Panel manufacturer Hisense Panel model HD550H1U51-T0L2 Active display area, horizontal dimension 1209,6 Active display area, vertical dimension 680,4 Screen size (rounded to nearest integer) 139 Screen size (rounded to nearest integer) 55 Display technology LCD/ LED lit Backlight source Direct LED Resolution (Horiz x Vert) 3840X2160 Screen curvature radius – Colour depth 8bit Image refresh frequency 60 Smooth motion rate 60 3D image – Typical brightness of white 300 Native contrast ratio 4000：1 Viewing Angle (Horiz / Vert) 178/ 178 Quantum dot No Wide colour gamut No KSF phosphor No UHD Premium No Response Time 8 Connectivity RF- Radio frequency input 1 AV input 1 AV output 0 USB interface type 3.0 (Qty / List….) 0 USB interface type 2.0 (Qty / List ….) 2/ USB1, USB 2 Optical digital audio output (SPDIF) 1 Earphone jack 1 HDMI ports HDMI inputs 3 HDMI type 8K@60Hz No HDMI type 4K@60Hz with HDCP version 2.2 3*HDMI2.0 (ALLM, VRR(48-60Hz)) HDMI 2.1 compliant input NO Enhanced Audio Return Channel ( eARC) Yes CEC- Consumer Electronics Control via HDMI Yes Smart TV Ethernet port (RJ45 connector) 1 Wi-Fi protocols IEEE 802.11 {b, g, n, ac, ad, ..} a, b, g, n, ac Wi-Fi bands 2.4/5.0 DLNA compliance Yes Bluetooth / BT version Yes / 5.0 Anyview (Screen mirroring) Yes BVOD services (Iview, SBS on Demand, 9Now, 7Plus, Tenplay) Iview, SBS on Demand, 9Now Installed Applications {List ……} Netflix/Youtube/Prime Video…… Freeview Plus – HbbTV 2.0 Yes Web browser [Chrome | Opera | Other] Odin Digital TV reception Digital broadcating (DVB-T / DVB-T2) Yes / Yes Video decoder (MPEG2 / MPEG 4) Yes / Yes LCN- Logical channel number and DTV Service name support Yes Teletext / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX Yes / Yes / Yes Subtitles Yes EPG- Electronic programming guide, 7 days for all services Yes Audio description (vision impairment aid) Yes Parental rating lock Yes Analog Tuner Yes Image processing Backlight control Yes Light sensing No Dynamic backlight control No Frame rate control No Variable Refresh Rate (VRR) Yes FreeSync No Auto Low Latency Mode for VRR Yes Local dimming/ controllable zones No Zoom function settings Automatic/ 16:9/ 4:3/ Panoramic/
Movie Zoom/ DirectHDR – High Dynamic Range for luminance (DMP / Netflix / HDMI) Yes / Yes / Yes HDR system (HDR10 / HDR10+ / Dolby Vision) No/ No / YES HLG (Hybrid Log-Gamma) for HDR YES HEVC (H.265) decoder Yes Motion enhancement and compensation (MEMC) No Picture mode Standard,Cinema Day,Cinema Night,Dynamic,Sports Sound Audio power output per channel 8 Number of speakers (Tweeter / Midrange / Woofer) 0/2 /0 Automatic volume level (AVL) Yes Audio equalizer Yes Dolby Digital Yes Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….} DTS Virtual X Lip-sync adjustment Yes Sound mode Stand,Theatre,Music,Speech,Late Night,Sports. Features On/off timer Yes Power off if no signal Yes Sleep timer Yes Program lock Yes OSD transparency control Yes User interface VIDAA U6 Software version OSD indication Yes Legal requirements: Disclaimer / Acceptance of Terms Yes / Yes Favourite channels list Yes Electronic point of sales (E-POS) Yes OTA- Over the air software updates Yes Voice command Yes Screen mirroring {Miracast, Anyview Cast, …} Screen Sharing Smartphone remote control application {Rremote Now, …} Yes Replaceable demo video for Store mode Yes Remote control via serial port No USB media player Personal Video Recorder Yes Time Shift Yes DTV Recording (EPG scheduling / start from Standby ) Yes / Yes DivX decoder No MPEG4 (H.264) / H.265 decoder Yes / Yes DMP- Digital media player content (Music / Video / Photos / Text) Yes / Yes / Yes / No DMP Auto-play No DMP for UHD content via USB Yes DMP File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes / No / Yes PVR File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes / No / Yes Hotel lock Protected Hotel lock submenu (Password / fixed code) No / Yes Clone function for programs, sound and image settings. Yes Sub-menu lock, including tuning lock Yes Keyboard lock Yes Maximum volume lock Yes Power on volume Yes Power on, apply default sound/image settings No Power on source selection Yes Power on RF channel selection Yes Power on mode (On / Standby / Last) Yes / Yes / Yes Inputs access (Enable / Disable) Yes Hardware Processor / Cores MT9602R Dual Tuner No Colour (Front bezel, rear, stand) Black / Black / Black Speakers mounted in enclosure Yes Mains power switch No Swivel base No Compact packaging Yes Supply range [Voltage / Frequency ] 100 ~ 240V，50Hz/60Hz Standby consumption < 0.5W Maximum time delay Power On to sound an image 30 Installation Stand area (Width / Depth) 973×274 Wall mount dimensions (Horiz x Vert) 200×400 Wall mount, screw thread M6/10 VESA compliance Yes Detachable power cord Yes Power cord length 155 Accessories Remote controller (Technology / Part number ) IR /EN2K36H(0011) Battery (size / quantity) AAA / 2 User manual (Available online) / Quick setup guide (Print) 1 / 1 Warranty [In User manual | In separate sheet] In separate sheet Skype camera (Qty / Part number) – 3D glasses type [Passive | Shutter] / Link [RF | IR | BT] – 3D glasses (Qty / Part number) – Dimensions Dimensions with stand (W x H x D) 1233×767×274 Dimensions without stand (W x H x D) 1233×715×80 Carton box dimensions (W x H x D) 1400×839×135 Net weight (with stand / without stand) 11Kg/10.9 Kg Gross weight 16.5Kg Container load (20ft / 40ft / 40ft HC) 140/284/426 Licensing and certification EMC- Electromagnetic Compatibility Yes CB- Electrical safety Yes HDMI Yes (Hisense internal test) Dolby Digital Yes MEPS- Test report Yes ROHS No Electrical safety conformity for Australia Yes Documentation CB report and certificate Yes EMC report and certificate Yes Power cord, plug and connector Australian safety approval Yes
