Description
| Network standards | IEEE 802.3、 IEEE 802.3u、IEEE 802.3x、IEEE 802.3af、IEEE 802.3at |
| LED Indicator | 5* Link/Ack LED indicators 1 * Power LED indicator |
| Interfaces | 5*10/100/1000 Base-T Ethernet Ports(Data/Power) 1*10/100/1000 Base-T Ethernet Port(Data) |
| Transmission media | Recommended: CAT5/5e UTP or better |
| Dimension | 100.0mmx100.0mmx27.0mm |
| Level of protection | Lightning protection for ports: 6kV Lightning protection for power: 6kV ESD: Air discharge: ±10kV Contact discharge: ±8kV |
| Forwarding mode | Store-and-forward |
| Switch capacity | 10 Gbps |
| Packet forwarding rate | 7.44Mpps |
| Buffer | 1M |
| MAC address table | 2K |
| PoE budget | Single port: AF: 15.4W, AT: 30W Whole device: 58W |
